Product Overview
This smart switch module operates on the Zigbee 3.0 protocol and requires a compatible Zigbee hub to function; it does not connect directly to Wi-Fi. It offers remote control capabilities for various home appliances and DIY projects, such as garage door openers. The module supports multiple operating modes including self-locking and inching.
Key Features
- Requires a Zigbee hub (sold separately) for setup and operation.
- Compatible with various Zigbee 3.0 hubs.
- Supports quick pairing with Zigbee gateways.
- Can be controlled via voice commands with Alexa and Google Home when connected to a compatible hub.
- Offers three working modes: self-locking, inching, and interlock.
- Suitable for DIY projects and controlling home appliances.
How to Use
Connect the smart switch module to your power source (USB 5V or DC 7-32V). Pair the module with your Zigbee gateway hub following the hub's instructions. Once paired, you can control the connected devices through the Zigbee hub's app or compatible voice assistants like Alexa or Google Home.
Specifications
- Brand: Huacaoe
- Operating Voltage: USB 5V or DC 7-32V
- Current Rating: 10 Amps
- Circuit Type: 4-way, parallel
- Contact Type: Normally Open
- Connector Type: Plug In
- Terminal Type: Plug in
- Contact Material: Metal
- Switch Type: Relay
- Mounting Type: Tabletop
- Dimensions (L x W x H): 3.15 x 2.95 x 1.14 inches
- Protocol: Zigbee 3.0
- Requires: Zigbee Hub (not included)
